The Dewpointe® 11-Stage Filtration System
Our dedication to high-quality, great tasting water is accomplished by a unique multi-stage filtration and water purification system.
The electrostatic air filter removes small particles such as pollen, pet dander, dust, mold, and fungi.
After the moisture has been extracted from the air, the water passes into the unit’s bottom reservoir through an activated carbon filter.
A germicidal 4-watt UV light destroys bacteria and microorganisms.
The inline sediment filter removes ammonia, volatile organic compounds, soil particles, etc.
The water is pumped through the first of two pre-carbon (coconut hull) filters, which eliminate heavy metals, chlorine residuals, and mineral salts.
A second pre-carbon filter ensures complete filtration of metal compounds.
The water then travels through the zero-waste reverse osmosis filter to be cleansed of any remaining pathogens or micro-fine particles. Unlike other R.O. systems, our system takes the wastewater and diverts it back to the bottom holding tank to be reprocessed so that no precious water is wasted.
From here the water moves to the post-carbon filter, which eliminates any odors and enhances the clean sparkling taste.
Before the water is directed to the stainless steel upper reservoir, it’s pumped through a second post-carbon filter.
An 11-watt UV sterilization light eradicates potential bacteria in top tank.
Finally, an 11-watt inline UV sterilization lamp guarantees that clean, fresh water is always dispensed from the water faucet.
|
| Can be shipped to customers in
the contiguous U.S. only. Cannot be shipped to P.O. boxes.
Express delivery not available. |
| 44”H x 16”W x 16”D. 90.8 lbs. |
Floor-Standing Consumer Atmospheric Water System Special Features:
11 internal filters, 3 UV (2 @ 11W, 1 @ 4W), hot and cold dispensing, full-featured touch-screen display including real-time temperature and humidity, stainless steel holding tanks, casters for easy moving and cleaning, micro-computer that monitors all working parts, energy-saving sensors, child-proof hot water lock, Venturi fan design, electrostatic air filter, and fail-safe auto-shut off features. 500W/hour in use; 80W/hour standing. |
Dewpointe DH9 has an advanced 11-stage filtration system. Here is a list of the filters in order of flow:
1. Electrostatic Air Filter
2. Zeolite/ Activated Carbon Lower Tank Filter
3. Lower tank line-out sediment filter
4. Lower Tank 4-watt UV light (Phillips)
5. Pre Carbon (coconut hull) Filter I
6. Pre Carbon (coconut hull) Filter II
7. Dow Zero-waste R.O. Filter (.0001 micron)
8. Post Carbon (coconut hull) Filter I
9. Post Carbon (coconut hull) Filter II
10. Top Tank 11-watt UV light (Phillips)
11. Hot Water In-Line 11-watt UV light (Phillips)
The internal filters (the outer air filter does not need to be replaced) should be replaced about once a year, or as indicated by the filter life sensor displayed on the monitor. The only exception is the RO membrane, which should be replaced approximately once every two years or as needed. |
| The Dewpointe® is a remarkably simple, yet highly effective appliance that creates drinking water out of the abundant supply of moisture in the atmosphere. It uses the most current water purification technology available to ensure a dependable production of the world’s purest water for your home or business. The Dewpointe®’s microcomputer analyzes temperature and humidity and supervises system functions so that maintenance and operations are easy and efficient.
STAGE 1: Air Filtration
The first electrostatic air filtration stage removes dust, pollen, mold and other airborne contaminants as humid air enters the Dewpointe®. Atmospheric water production immediately eliminates 95% of contaminants found in municipal ground water.
STAGE 2: Chilling the Air
The airflow through the filter system is rapidly chilled to “dew point”. This is the temperature at which the potentially unlimited water in the air transforms from a gas to a liquid.
STAGE 3: Condensation
Condensed moisture collects on the specially designed coils, which are covered with a FDA approved food-grade coating to prevent potential metal pollution. Once the Dewpointe® has completed the moisture “extraction” process, the water is delivered to an advanced multi-stage filtration system.
STAGE 4: Purification
The water passes through 10 specialized filters, including a proprietary activated carbon filter, four coconut hull carbon membranes, a zero-waste R.O. filter, and powerful UV light sanitation system. This comprehensive purifying system provides unparalleled removal of contaminants and microorganisms. At this point, the Dewpointe®’s water is 99.99% pure.
STAGE 5: Water Temperature Optimization
The hot & cold water lines pull from a sealed stainless steel holding tank, providing chilled and hot water on demand. In just five stages, the Dewpointe® transforms atmospheric moisture into delicious, rain-fresh drinking water! |
| Tech Specs |
Shipping Info |
Dimensions |
Features |
Use & Care |
Product Story |
|
|
|
|
|
01-2003 |
DewPointe DH9 Atmospheric Water Purification System
|
|
Original: $1,999.00
Sale: $1,595.00
|
|
|
